Terraform Tricks – Working With Multiple Provider Instances

One of the lesser known functions of Terraform is the ability to operate multiple instances of the same provider within the same configuration. The uses of this are various though as it’s not always needed it’s one of those things that doesn’t always leap out. It’s pretty easy to get to grips with so this is a short post to take a look at how to get started.

Providers – A Quick Recap

In the world of Terraform, a Provider is used to allow Terraform interface with the API for a Cloud (or other infrastructure) platform and expose it’s resources to allow provisioning and configuration from a Terraform configuration. Countless providers exist now both officially and in the community world.

By default when Terraform is initialised providers are automatically installed, however by default a provider is automatically configured with a single static set of configurations, let’s take a look at a standard provider configuration for AWS which is looking up it’s secret credentials from Vault:

provider "vault" {
    skip_tls_verify = false
}

provider "aws" {
    region          = "eu-west-2" #--London
    access_key      = data.vault_generic_secret.aws_credentials_london.data["aws_access_key_id"]
    secret_key      = data.vault_generic_secret.aws_credentials_london.data["aws_secret_access_key"]
}

By default any Terraform configurations which use AWS resources will now be created/modified within the eu-west-2 region (London).

This is all fine for a single region configuration, but what happens if we have some resources in London and some in Ireland (eu-west-1), we don’t want to have to keep switching between configurations. Luckily the solution already exists in the form of provider aliases.

Provider Aliases

By using aliases within our provider configurations we can set up multiple instances of the same provider, in the below example we are setting up two AWS providers, one for eu-west-1 with the alias Ireland and one for eu-west-2 with the alias London:

provider "vault" {
    skip_tls_verify = false
}

provider "aws" {
    alias           = "Ireland"
    region          = "eu-west-1"
    access_key      = data.vault_generic_secret.aws_credentials_london.data["aws_access_key_id"]
    secret_key      = data.vault_generic_secret.aws_credentials_london.data["aws_secret_access_key"]
}

provider "aws" {
    alias           = "London"
    region          = "eu-west-2"
    access_key      = data.vault_generic_secret.aws_credentials_ireland.data["aws_access_key_id"]
    secret_key      = data.vault_generic_secret.aws_credentials_ireland.data["aws_secret_access_key"]
}

Now we can specify which instance of these provider instances we wish to use when provisioning resources. In the below example we’ll create a VPC in each region:

resource "aws_vpc" "tinfoilvpc_ireland" {
    provider   = aws.ireland
    cidr_block = "10.1.0.0/16"
}

resource "aws_vpc" "tinfoilvpc_london" {
    provider   = aws.london
    cidr_block = "10.2.0.0/16"
}

The specific provider is referenced within the main stanza as <provider_name>.<provider_instance>, in this example aws.ireland and aws.london.
