I’ve been playing a lot with Crossplane recently and found myself a little stuck trying to create additional Kubernetes resources using Crossplane itself as the orchestration layer. This is pretty well documented in disparate places, but I haven’t seen it covered anywhere top to bottom so in this short post I’ll try and cover the topic off.

Installing and Configuring the Kubernetes Provider

In this example I am installing the Kubernetes Provider and creating a ClusterProviderConfig to serve it out to all tenants. Since we don’t have to think about authenticating with a cloud provider like AWS, we can keep everything inside the cluster and that should make our lives a lot easier. For the most part this installation behaves the same as all others, with the exception of how the credential source is handled:

apiVersion: pkg.crossplane.io/v1
kind: Provider
metadata:
  name: provider-kubernetes
spec:
  package: xpkg.upbound.io/upbound/provider-kubernetes:v1.1.0
---
apiVersion: kubernetes.m.crossplane.io/v1alpha1 #--Namespaced endpoint
kind: ClusterProviderConfig #--Cluster wide
metadata:
  name: kubernetes
spec:
  credentials:
    source: InjectedIdentity #--Use the provider's existing SA

The credential source above is configured to use an InjectedIdentity. What this means is that the Service Account attached to the Kubernetes Provider Pod is used as the source of auth when attempting to create resources. When a provider is installed the Crossplane RBAC Manager automatically creates a SA and binds it to a ClusterRole with a suitable set of permissions (it’s a pretty cool system).

With the Kubernetes Provider this is quite limited in what you can do by default, limiting you to creating ConfigMaps, Secrets and managing other Crossplane resources. But if you want to widen the scope of this you only have to create your own SA and attach it to the provider as shown below:

apiVersion: pkg.crossplane.io/v1beta1
kind: DeploymentRuntimeConfig
metadata:
  name: kubernetes
spec:
  serviceAccountTemplate:
    metadata:
      name: provider-k8s-enhanced #--Your SA name here
---
apiVersion: pkg.crossplane.io/v1
kind: Provider
metadata:
  name: provider-kubernetes
spec:
  package: xpkg.upbound.io/upbound/provider-kubernetes:v1.1.0
  runtimeConfigRef:
    name: kubernetes #--Links to the Runtime Config above

With a Provider installed and configured, you can created Kubernetes resources by passing manifests nested within the Crossplane MR type object.kubernetes.m.crossplane.io as shown below:

apiVersion: kubernetes.m.crossplane.io/v1alpha1 #--Namespaced resource
kind: Object
metadata:
  name: tfc-example-secret
spec:
  forProvider:
    manifest:
      #--Begin Kubernetes object manifest
      apiVersion: v1
      kind: Secret
      metadata:
        name: tfc-example-secret
        namespace: tenant1
      data:
        secret_information: c29tZXJ1YmJpc2gK
      #--End kubernetes object manifest
  providerConfigRef:
    name: kubernetes #--Created above
    kind: ClusterProviderConfig

We can see the resource has created and can be looked up using regular Kubernetes verbs:

kuebctl get secrets -n tenant1
NAME                TYPE           DATA   AGE
tfc-example-secret  Opaque         1      1m
